ACRO CNC 1000mm x 1000mm Silver – Mechanical Kit

$328.50 Inc. GST

Found a lower price? Click here and we will beat it by 5%!

The ACRO CNC is suitable for mounting a 5-20W Blue Light Lasers.  Featuring light weight plates made from precision cut acrylic to ensure the entire machine weight is kept to a minimum.

Please note this listing is for the mechanical kit including stepper motors. Lasers and other electronics are not included.

LCN: N/A SKU: KIT-ACRO-1010-S Category: Tags: , ,

Description

The ACRO CNC was originally designed by OpenBuilds USA and shared Open Source under the CC BY-SA 4.0. The Maker Store ACRO system is based on the original design however there are some small differences, most noticeably the V-Slot comes pre-tapped eliminating the need for tapping the extrusion during the assembly. The ACRO CNC is suitable for mounting a 5-20W Blue Light Lasers. The ACRO system can easily be adapted to be almost any size imagined due to its effective modular design. Featuring light weight plates made from precision cut acrylic to ensure the entire machine weight is kept to a minimum.

Please note this listing is for the mechanical kit including stepper motors. Lasers and other electronics are not included.



What is the ACRO?

The ACRO was designed by OpenBuilds USA as a light weight and fast laser CNC machine suitable for hobby applications. The OpenBuilds ACRO was developed to be the most accurate and cost effective system in its class. The ACRO System incorporates the modular V-Slot system and, therefore, has the unique ability to expand to multiple sizes creating a size configuration custom to your needs.

What can you do with the ACRO system?

The ACRO system is originally designed to be a Laser CNC platform suitable for Blue Light Lasers between 5-20W. With some small modifications the ACRO can also be used as a drawing machine by mounting a marker or fountain pen to the gantry.

Bill of Materials:

DescriptionSKUQTY
GT2 (2mm) Timing Belt (per meter)BELT-GT2-5MM-1M4
GT2 (2mm) Aluminum Timing Pulley 20BELT-GT2-TP203
Black Angle Corner ConnectorsBRAC-90ANG4
L-Bracket – SingleBRAC-L14
Nema 17 Stepper Motor 560mN.m – Version BELEC-NEMA17-B3
Nylon Insert Hex Locknut – M5HARD-NUT-LOCK-5MM20
Slot Cover / Panel HolderHARD-SC-RED4
Tee Nuts – M5HARD-TNUT-110
Double Tee NutHARD-TNUT-26
Drop In Tee Nuts – M5HARD-TNUT-DROP-M510
V-Slot 20 x 20mm – 1000mmLR-2020-S-10002
V-Slot 20 x 40mm – 1000mmLR-2040-S-10003
ACRO Acrylic Plate SetPLATE-ACRO-SET1
Button Head Screws M3 – 10mmSCREWS-M3-BH-10-114
Button Head Screws M3 – 16mmSCREWS-M3-BH-16-12
Low Profile Screws M5 – 10mmSCREWS-M5-LP-10-18
Low Profile Screws M5 – 15mmSCREWS-M5-LP-15-120
Low Profile Screws M5 – 20mmSCREWS-M5-LP-20-14
Low Profile Screws M5 – 30mmSCREWS-M5-LP-30-18
Low Profile Screws M5 – 40mmSCREWS-M5-LP-40-14
Low Profile Screws M5 – 8mmSCREWS-M5-LP-8-14
Set Screw M5 – 4mmSCREWS-M5-SET-4MM6
Self Tapping ScrewSCREWS-SELFTAP-20/14
Precision Shim – 10x5x1mmSHIM-PREC-105118
Precision Shim – M3 7×3.2x05mmSHIM-PREC-M32
Metric Aluminum Spacers – 6mmSHIM-SPAC-6MM18
8mm SpannerTOOL-SPANNER-81
Solid V Wheel KitsWHEEL-SOLIDV-KIT12
Allen Key/Wrench Ball End 3mmTOOL-ALLEN-BALLEND-31
Allen Key/Wrench Ball End 2.5mmTOOL-ALLEN-BALLEND-2.51
Allen Key/Wrench Ball End 2mmTOOL-ALLEN-BALLEND-21

Credits: The ACRO System was designed by the team at OpenBuilds USA. Maker Store is a proud registered distributor of the Open Source line of products based on the designs by OpenBuilds. Images used courtesy of OpenBuilds LLC.
